Insulated Truck Transport Refrigerated Units Cooling units With Aluminium Alloy Fan

Model NO. : SF-550

Installation : Front Mounting Type

Electric : Optional Electric Standby System

Colour : White

Fan Material : Aluminium Alloy

Condensor Design : Latest Exclusively for Refrigeration Unit

Sealing Technology : Patented O Sealing Technology

Design Base Environment : 45 Degree C

Durability Range : The Highest Level

Maintenance : Lower The Cost of Maintance

Transport Package : Plywood Package

Trademark : SNOWFALL

Origin : Guangzhou, China

HS Code : 8418692090

Supply Ability : 350 Sets Per Month

Certification : ISO9000

Transmission Type : Automatic

Bearing Capacity : Large

Car Type : Truck

Condition : New

Service : OEM

Customization : Available | Customized Request

Contact Now

Insulated Truck Transport Refrigerated Units Cooling units With Aluminium Alloy Fan

Introduce:
It is suitable for refrigerating vehicles of light trucks and above, with remarkable refrigeration effect under the volume of 14-23m

It is the first choice for supermarket, food and beverage distribution, and pork refrigerating truck. Its refrigeration performance is very stable and reliable.
The SF-550 all-in-one engine driven transport refrigerating unit is a reliable refrigerating unit for light truck thermal insulation vehicles with a size of 14~ 23m.

Feature:

Optional DC 12V or 24V for you to choose, and backup electric refrigeration system DC220V/DC380V optional installation.
The whole transport refrigerating unit is easy to install, expands the effective loading space, and the 12-inch super large aluminum alloy vane motor imported from Taiwan
This series of models fully covers the freezing capacity ranging from 14 m to 23 m and accurately matches its freezing volume from per square meter.
Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.

Unit Model		SF-550
Applicable Temperature		25 °C ~ - 20 °C
Cooling Capacity	Environmental Temperature	35 °C
	0 °C	5000Kcal/5815W/19841BTU
	-18 °C	3100Kcal/3605W/12300BTU
Compressor	Model	UX200
	Displacement(cc/r)	200
Condenser	Type	P.F.
	Fan Type	Axial Fan
	Number of Fan	2 Fans * 1000m ³/h
	Voltage	DC 12V / DC 24V
Evaporator	Type	Inner screw tube and aluminium fin
	Fan Type	Axial Fan
	Number of Fan	3 Fans * 1000m ³/h
	Voltage	DC 12V / DC 24V
Power Comsumption		≤36A(DC 12V) ≤20A(DC 24V)
Refrigerant		R-134a/R-404a
Defrost Type		Automatically hot air defrost
Structure		Integral unit
Electrical Standby System (optional part)		AC 220V / AC 380V/ 415V
Dimensions(mm)		1665760480
Net Weight(kg)		106kg
